| Media: | Water, Liquid, Gas, Steam, Oil, Lubricant | Output Signal: | 4- 20mA, 0.5-4.5V, 0-5V, 1-5V, I2c, Other |
|---|---|---|---|
| Pressure Range: | -100Kpa ~ 60MPa | Material: | 304 SS, 316L |
| Model Number: | WNK81mA | Accuracy: | 0.5% , 1.0% FS |
| Place Of Origin: | China | Operating Temperature: | -40~85 ℃ |
| High Light: | oem pressure sensor,precision pressure sensor,Water Treatment Electronic Pressure Sensor |
||
Product Discription
Application in water treatment and water conservancy monitoring:
With the development of science and technology, water conservancy power generation, hydrological monitoring, sewage treatment,constant pressure water supply and other industries have increasingly higher requirements for timely data feedback and control of field pressure. Pressure sensor provides first-hand information for the discovery and processing of field problems.
WNK81mA pressure sensor is generally used in the balance water tank and the balance water tank in the water treatment system as a liquid level sensor. The pressure data returned by the pressure sensor is controlled by the frequency converter to start or stop the pump.
WNK81MA products are small in size and high in accuracy, and are used in industrial sites, urban water supply and sewage treatment, hydrological monitoring and control, large river dams and water conservancy construction, marine and marine systems, instrument and beverage equipment, chemical equipment, medical equipment, water conservancy and hydropower monitoring.
| Product Name | WNK81mA Diffused Silicon Pressure Sensor Transducer For Water Treatment System | |||
| Pressure Type | Gauge pressure, sealing pressure, absolute pressure | |||
| Measure Range | 0-20kPa~60MPa | |||
| Output | 0.5-4.5v, 4-20mA, I2C, 0-5V, 0-10V, customize | |||
| Accuracy | 0.5%FS, 1%FS | |||
| Compensation Temperature | -20…70ºC | |||
| Ingress | IP65/IP67 | |||
| Working Temperature | -45 to 85ºC, | |||
| Electrical Connection | Packard, M12*1, Cable outlet, Mini DIN43650, Customize | |||
| Process Connection | G1/4, 1/4NPT, 1/8NPT, M12*1.5, Customize | |||
