IP68 Waterproof Small Oil Water Pressure Sensor 0-10 MPa Pressure Range

Good quality Water Pressure Sensor for sales
Good quality Water Pressure Sensor for sales
I'm Online Chat Now

IP68 Waterproof Small Oil Water Pressure Sensor 0-10 MPa Pressure Range

China IP68 Waterproof Small Oil Water Pressure Sensor 0-10 MPa Pressure Range supplier

Large Image :  IP68 Waterproof Small Oil Water Pressure Sensor 0-10 MPa Pressure Range

Product Details:

Place of Origin: Hefei, CN
Brand Name: WNK
Certification: CE, SGS, ISO9001
Model Number: WNK811

Payment & Shipping Terms:

Minimum Order Quantity: 5 pieces
Price: Negotiation
Packaging Details: Sea-Worthy Packing or Air-Worthy Packing
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 8000pcs per month
Contact Now
Detailed Product Description
Output: 4~20mA, I2C, SPI, 0.2-2.9V, 0-5V And Customization Pressure Range: 0-10MPa
Operation Temperature: -40~150℃ Accuracy: 0.5%FS, 1%FS, 2%FS
Overload: 2 Times FS Proof Pressure: 3 Times FS
Respond Time: ≥1ms OEM: OEM, ODM And Customization Available
Housing Material: SS304 Sensor Type: Diffused Silicon Sensor, Ceramic Capacitive Sensor



IP68 Waterproof Small Oil Water IOT Pressure Sensor 0-5V, 4~20mA



WNK80MA is a series of high performance compact pressure transmitter by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. In addition to general ranges of normal sensors, its most outstanding characteristic is the positive and negative gauge pressure function. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.



Features :

  • Various 4~20mA/0.5~4.5V/1~5V/ 0~5V/ SPI/ I²C outputs available;
  • High performance ceramic capacitive pressure sensor or diffused silicon pressure sensor;
  • Temperature range: -20 to 85ºC;
  • Wide operation temperature range -40~125ºC;
  • Optional packard, M12, Small Hirschman connectors and direct cable outlet;
  • Small dimensions, dimension customizble;
  • OEM, ODM, customization service available;



Detailed Technical Info:



Small Oil Water IOT Pressure Sensor
Pressure range  0~10bar
Pressure type Gauge, Absolute, Sealing gauge
Overpressure 300%F.S. (≤70kPa) 200%F.S.(≤25MPa)
Output signals 0.2-2.9V, SPI, I2C, 0.5-4.5V, 1-5V, 0-5V, 0~10V, 4~20mA
Accuracy ±0.5%FS, ±1%FS
Compensation Temp. -20~70℃
Operation Temp. -40~125℃
Storage Temp. -40~125℃
Zero Temp. Drift ±1.5%FS Max (-20~85℃)
Full Scale Temp. Drift ±1.5%FS Max (-20~85℃)
Pressure Connection G1/4, 7/16-SAE, NPT, and other outputs
Ingress Protection IP67
Housing SS316, SS304





Competitive Advantages:

1. Founded in 2004, over 13 year professional research, developing and production experience;
2. Experienced and professional R&D team to provide customization services;
3. Producing transmitter core elements- PCB, supplying PCB for transmitter producers;
4. Highest accuracy up to 0.05%FS;
5. Various outputs I2C, SPI, 4~20mA, Hart, Modbus, Profibus-Pa, 0.5-4.5V, 0.2-2.9V and other analog outputs;
6. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
