IP65 Air Pressure Sensor 4-20mA Output for Air Gas HVAC Application

Good quality Water Pressure Sensor for sales
Good quality Water Pressure Sensor for sales
I'm Online Chat Now

IP65 Air Pressure Sensor 4-20mA Output for Air Gas HVAC Application

China IP65 Air Pressure Sensor 4-20mA Output for Air Gas HVAC Application supplier

Large Image :  IP65 Air Pressure Sensor 4-20mA Output for Air Gas HVAC Application

Product Details:

Place of Origin: ANHUI, CHINA
Brand Name: WNK
Certification: ISO,Exia
Model Number: WNK808B

Payment & Shipping Terms:

Minimum Order Quantity: 10 set
Price: Negotiation
Packaging Details: standard export carton packing
Delivery Time: 3~5 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 200 set/day
Contact Now
Detailed Product Description
Measure Media: Air, Gas Output Signals: 4~20mA
Accuracy: 0.2%, 0.5%, 1% Pressure Range: -100Pa~100Pa , 0-1kPa...60kPa
Protection Class: IP65 Housing Material: Aluminium
Power Supply: 10.5~30V DC Display: NO

Low Differential Air Pressure Sensor with 4-20mA Output for HVAC Application



WNK808B intelligent pressure transmitter is assembled with aluminum housing and stress isolation technology. Integrated structure design lead to compact layout. With intelligent compensation technology, it is suitable for wind pressure,wind speed & flow measurement. It is widely used in various industrial fields as well as intelligent building and other construction projects, such as power plant boiler primary air,secondary air measuring, mine ventilation,indoor ventilation, boiler air ,pressure of fan,air duct pressure,Metro wind pressure and environment wind pressure test.





Application

It is the best micro pressure measurement equipmenttextile for textile machinery,natural gas pipeline monitoring,dust removal system, HVAC,clean laboratory and medical equipment etc.





Technical data

Applicable media Gas
Pressure range -10Pa~100Pa, -100kPa~+100kPa
Pressure Measurement Gauge pressure, Differential pressure
Accuracy 0.2%, 0.5%
Stability 0.8%F.S./Year
Maximum static pressure 70 KPa
Max overload 250% of sensor range
Output signals 4~20mA
Housing material Aluminum14
Induct Pressure Connection: M 8x1 female or Ø 8 dowel connection
Power Supply Non-explosion: 10.5~45V DC
EEX ia:10.5~30 V DC
Ambient temperature -40~85℃
Compensation temperature -10~70℃
Working temperature -10~70℃
