0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply

Good quality Water Pressure Sensor for sales
Good quality Water Pressure Sensor for sales
I'm Online Chat Now

0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply

China 0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply supplier
0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply supplier 0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply supplier 0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply supplier 0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply supplier

Large Image :  0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply

Product Details:

Place of Origin: China
Brand Name: WNK
Certification: ISO, CE
Model Number: WNK83MA

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: Standard export carton box or according to your requirement
Delivery Time: 5-7 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000 Piece/Pieces per Month
Contact Now
Detailed Product Description
Accuracy: 1%F.S Output: 0.5-4.5V
Pressure Range: 0-1000Kpa Power Supply: 4.75-5.25VDC
Work Temperature: -20~70°C Measured Media: Liquid, Gas, Steam
Housing Material: Brass Electrical Connection: Cable Outlet

Oil/air/water ceramic pressure sensor/transducer water pressure sensor 0-1MPa

Parameter



Applicable media Liquid, gas, steam
Pressure range 0-1000Kpa
Pressure measurement Gauge pressure, sealing pressure
Output 0.5-4.5V
Power Supply 4.75-5.25VDC
Accuracy(lineraity, hysteresis, repeatability) 1%FS
Work temperature -20~70°C
Storage temperature -40~110°C
Temp drift(zero) ±0.15%FS(-20~70°C)
Temp drift(full range) ±0.15%FS(-20~85C)
Electrical connection Parkard
Mechanical connection Cable outlet
Housing material Brass









Mechanical Dimension



0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply











Company Information



0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply


Factory


0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply




Exhibition


0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply





Our Certificate
0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply





Packing
0 - 1MPa Air Pressure Sensor Water Pressure Sensor Lightweight 4.75 - 5.25VDC Power Supply

FAQ


Q: Are you manufacturer or trading company?

A: We are professional pressure/level/temperature measurement manufacturer since 2004.



Q: What’s your quality control system?

A: We are an ISO 9001-2015 certified manufacturer, we have strict quality control system. Besides clibartiaon, each set product we also do temperature compensation and aging test before shipment, so the quality is guaranteed.



Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.



Q: Can we use our logo on the products? Do you provide customized products?

Yes.we can use your logo, we can provide customized products per requirement. OEM/ODM is welcome



Q: What is yor MOQ?

A: We have no MOQ limits, small quantity order is acceptable.



Q: What's the transport?

A: Express such as DHL, Fedex, TNT, UPS for freight prepaid, also can use your own couier account to do the freight collect. For more goods we can arrange by air or by Sea.
