4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification

China Hefei WNK Smart Technology Co.,Ltd certification
China Hefei WNK Smart Technology Co.,Ltd certification
I'm Online Chat Now

4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification

4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification
4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification 4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification 4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification 4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification

Large Image :  4-20ma 0.5-4.5V Piezoelectric Pressure Sensor ISO9001 Certification

Product Details:
Place of Origin: Hefei, China
Brand Name: WNK
Certification: CE, SGS, ISO9001
Model Number: WNK80MA-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: Sea-Worthy Packing or Air-Worthy Packing
Delivery Time: 5-7 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000 pcs per month
Detailed Product Description
Pressure Range: -1bar - 60bar Output: I2C, SPI, 0.5-4.5V, 4-20ma And Customization
Respond Time: ≥1ms Overload Pressure: 3-5 Times
Material: 304SS Sensor Type: Ioc Pressure Sensor
Working Temperature: -40 -135C Warranty: 12 Months
Ingress Protection: IP67 Accuracy: 0.25%FS, 0.5%FS 1.0%FS
High Light:

water level pressure sensor

,

i2c pressure sensor

4-20ma 0.5-4.5V Low Cost Piezoelectric Air Oil Water Pressure Sensor


Description

WNK80MA integral pressure transmitter adopts stainless steel shell structure, built in stainless steel oil filled sensor, intelligent digital circuit with precise temperature characteristic compensation, it can be used reliably and stably

Our sensor outputs including 4~20mA, SPI, I²C, 0.2~2.9V, 1~5V, 0~5V, 0.5~4.5V, 0~10v and etc. And OEM, ODM & customization service are available for this product.



Applications


- Automobile, Compressor and Refrigeration Industry

- Engineering machinery

- Pressure control and monitor

- Water treatment system

- Hydraulic and Pneumatics

- HAVC and BAS Control

- Pump, fitness equipment, household appliances

- Factory Automation

- Fluid Control and Instrumentation Systems



Features :

• Excellent resistance to corrosion and abrasion resistance;
• Adapt to pollution and corrosive environments;
• Flat large round diaphragm, easy to install;
• Rapid response, no hysteresis;
• Wide operating temperature range;
• Sensor-specific signal conditioning;
• 0.5 ... 4.5V voltage output or I2C digital output, 4-20mA output;
• Accurate, stable and reliable;


Technical Data


IOT Pressure Sensor

Pressure range

 -100kpa~70MPa

Pressure type

Gauge, Absolute, Seal, Vacuum

Overpressure

300%F.S. (≤70kPa) 200%F.S.(≤25MPa)

Output signals

0.2-2.9V, SPI, I2C, 0.5-4.5V, 1-5V, 0-5V, 0~10V, 4~20mA

Accuracy

±0.5%FS, ±1%FS

Compensation Temp.

-20~70℃

Operation Temp.

-40~125℃

Storage Temp.

-40~125℃

Zero Temp. Drift

±1.5%FS Max (-20~85℃)

Full Scale Temp. Drift

±1.5%FS Max (-20~85℃)

Pressure Connection

G1/4, 7/16-SAE, NPT, and other outputs

Ingress Protection

IP67

Housing

SS316, SS304



 Advantages:
1. Founded in 2004, over 13 year professional research, developing and production experience;
2. Experienced and professional R&D team to provide customization services;
3. Producing transmitter core elements- PCB, supplying PCB for transmitter producers;
4. Highest accuracy up to 0.05%FS;
5. Various outputs supported I2C, SPI, 4~20mA, Hart, Modbus, Profibus-Pa, 0.5-4.5V, 0.2-2.9V and other
6. Our products have been exported to most of the EU countries, North America, South East Aisia and other countries and regions.


Our company

WNK has 13-year experience of research, development, production and sales of sensors. With the concept of smart water management system, smart fire control, sponge city, smart city, and internet of things, WNK quickly seizes opportunities to develop low cost, low power, small size, with temperature measurement function ceramic capacitive pressure sensor.
After two years of research, development and repeatedly testings, our ceramic capacitive sensors have entered big quantity production stage. For different applications and installation methods, we offer OEM, ODM and customization services.
