IP65 4.5VDC Brass Capacitive Ceramic Pressure Sensor

IP65 4.5VDC Brass Capacitive Ceramic Pressure Sensor

Capacitive Ceramic Pressure Sensor

4.5VDC Ceramic Pressure Sensor

IP65 Water Pressure Sensor

Place of Origin:

China

Brand Name:

WNK

Certification:

CE

Model Number:

WNK83MA

Contact Us
Request A Quote
Product Details
Housing Material:
Brass
Output Singal:
0.5-4.5v
Ambient Temperature:
-40-125C
Pressure Type:
Gauge Pressure Sealing Pressure
Accuracy:
1%FS
Electrical Connection:
Packard, Cable Outlet
Pressure Range:
0-10Bar 0-20Bar
Process Connection:
1/4 NPT G1/4
Protection:
IP65
Highlight:

Capacitive Ceramic Pressure Sensor

,

4.5VDC Ceramic Pressure Sensor

,

IP65 Water Pressure Sensor

Payment & Shipping Terms
Minimum Order Quantity
1 piece
Packaging Details
Neutral carton packing or as per your requirement.
Delivery Time
5-8 work days
Payment Terms
D/P, T/T, Western Union, Paypal
Supply Ability
5000/ Piece/ Month
Product Description

0.5-4.5VDC Brass Capacitive Ceramic Pressure Sensor For Liquid Gas And Water



Product Description

WNK83 is a low cost ceramic capacitive pressure sensor. It uses our patented ceramic capacitive core pressure sensor, with accuracy of 1%FS, suitable for various IOT, IIOT and other process control fields. WNK83 has brass or stainless steel 304 housing and electrical connectors of Packard and direct cable. Its output is linearity 0.5-4.5V. With big stock, we ship you sensors very fast. As an original producing factory, OEM, ODM and customization services are welcome!

Applicable media water or liquid, gas
Pressure range

0-10bar, 0-20bar



Pressure measurement Gauge Pressure, Sealing Pressure
Output signals 0.5-4.5v
Power supply 4.75-5.25V DC
Accuracy ±1%FS
Total error band ±3%
Max pressure 2 times
Burst pressure 3 times
Supply current 15mA max
Electrical connection Packard Cable outlet
Process connection 1/4NPT, G1/4
Housing material brass
Protection class IP65
Working temperature -20-70c
Ambient temperature -40-110c



IP65 4.5VDC Brass Capacitive Ceramic Pressure Sensor 0IP65 4.5VDC Brass Capacitive Ceramic Pressure Sensor 1IP65 4.5VDC Brass Capacitive Ceramic Pressure Sensor 2

Company Information

IP65 4.5VDC Brass Capacitive Ceramic Pressure Sensor 3

FAQ



Q: Are you manufacturer or trading company?

A: We are professional pressure/level/temperature measurement manufacturer with more than 13 years of experience. Our factory address is: 4/F,Bldg #6, No.168, Xiangzhang Road, High-tech District, 230088, Hefei, Anhui province, China.



Q: What’s your quality control system?

A: We are an ISO 9001-2015 certified manufacturer, we have strict quality control system. Besides clibartiaon, each set product we also do temperature compensation and aging test before shipment, so the quality is guaranteed.



Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.



Q: Can we use our logo on the products? Do you provide customized products?

Yes.we can use your logo, we can provide customized products per requirement. OEM/ODM is welcome



Q: What is yor MOQ?

A: We have no MOQ limits, small quantity order is acceptable.



Q: What's the transport?

A: Express such as DHL, Fedex, TNT, UPS for freight prepaid, also can use your own couier account to do the freight collect. For more goods we can arrange by air or by Sea.
