| Pressure Range: | 0~600bar | Accuracy: | ±0.2%FS, ±0.5%FS, ±1.0%FS |
|---|---|---|---|
| Output: | 4~20mA; 1~5V, 0-10V And Other Analog Outputs | Long-term Stability: | ±0.25% Full Scale Per Year |
| Temp. Compensation: | -10 ~ 70 Deg C | Working Temperature: | -40 ~ 85 Deg C |
| Explosion Proof: | Intrinsically Safe | Electrical Connector: | DIN43650 (Hirschman), M12, Direct Cable Outlet And Others |
| Media: | Medium Compatible With SS304 And SS316L | Clamp Outer Diameter: | 50.5mm Or 64mm |
| Pressure Type: | Gauge, Absolute, Vacuum, Negative Pressure | Housing Material: | SS304 |
| High Light: | DIN43650 sanitary pressure transducer,DIN43650 hygienic pressure sensor,M12 sanitary pressure transducer |
||
DIN43650 M12 Direct Cable Outlet Sanitary Pressure Sensor For Medical
Product Description
Sanitary type WNK805 is specially designed for food and medical application. It has standard 50.5mm and 64mm outer diameter, connecting with process sanitary pipe directly and easily. Sanitary clamp type pressure transmitter is widely used in food, pharmaceutical, wine making, fermentation and other industries. It is divided in normal sanitary, high temperature cooling type, digital display types.
With a team of R&D engineers, we offer OEM, ODM and customization services.
Features:
Application fields:
1.Food hygiene industry；
2.Paper industry；
3.Sewage level measurement；
4.Beverage tank level measurement；
5.Pipeline level measurement；
6.Pharmaceutical and biological products processing
Product Spec
| Applicable media | medium compatible with SS304 and SS316L |
| Output | 4-20ma/1-5v/0-10v |
| Power supply | 24V |
| Accuracy | ±0.2%FS, ±0.5%FS, ±1.0%FS |
| Long-term Stability | ±0.25% full scale per year |
| Temp. compensation | -10 ~ 70 Deg C |
| Explosion proof | Intrinsically safe |
| Pressure type | gauge, absolute, vacuum, negative pressure |
| Clamp outer diameter | 50.5mm or 64mm |
| Housing material | SS304 |
