ISO9001 4~20mA 0.5-4.5V Digital Pressure Transmitter With Cooling Fins

ISO9001 4~20mA 0.5-4.5V Digital Pressure Transmitter With Cooling Fins
ISO9001 4~20mA 0.5-4.5V Digital Pressure Transmitter With Cooling Fins ISO9001 4~20mA 0.5-4.5V Digital Pressure Transmitter With Cooling Fins

Large Image :  ISO9001 4~20mA 0.5-4.5V Digital Pressure Transmitter With Cooling Fins

Product Details:
Place of Origin: Hefei, CN
Brand Name: WNK
Certification: CE, SGS, ISO9001, NEPSI
Model Number: WNK805-C
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: Sea-Worthy Packing or Air-Worthy Packing
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union
Supply Ability: 5000pcs per month
Detailed Product Description
Pressure Input: -100Kpa -0~ 600Bar Analog Output: 4~20mA 0.5~4.5V
Response Time: <2ms Sensor Type: Gauge, Absolute, Vacuum, Negative Pressure
Long-term Stability: 0.2%FS Per Year Temperature Compensation: -20C ~ 70C
Media: Gas Water Liquid Steam Stability: 0.25% FS/ Year
Housing Material: SS304, SS316
High Light:

smart pressure sensor

,

digital pressure transmitter



ISO9001 4~20mA 0.5-4.5V Smart Pressure Transmiter Transducer With Cooling Fins





WNK805 is widely applied in gauge or absolute pressure measurement in fields of aerospace, communication, irrigation works, oil, chemical, power, meteorology, laboratory and etc. It could also be used for measuring negative pressure, vacuum degree and etc.

The product is designed to work well for measuring all kinds of air, liquids, gas, fluids, even though weak-corrosive media under all-weather environments. The temperature compensation resistance makes on the ceramic base, which is the excellent technology of the pressure transmitters. Widely output signals are available.




Specifications



1. Pressure range: 0-0.2 ~ -100kPa, 0-0.2 ~ 1000kPa 60000kPa
2. Pressure type: gauge, absolute, vacuum, negative pressure
3. Overload: 1.5~2 times
4. Non-linearity: 0.1, 0.25, 0.5, 1%FS
5. Delay / repeat: 0.05, 0.1%FS
6. Temp. compensation: -10-70 ºC
7. Working temperature: -40 ~ 85 ºC
8. Media: nonconducting and non-corrosion or weak corrosion gas
9. Comprehensive accuracy: 0.1, 0.25, 0.5, 1.0
10. Stability: 0.25%FS/ Year



Application

This type water pressure sensor can be used to measure & control the pressure of liquids in the fields :

  • Water treatment
  • Petroleum, Chemical industry
  • Light industry, Metallurgy
  • Electric power, Water supply
  • Environmental protection
  • Oil & Gas, Forklif



Advantages:

1. Founded in 2004, over 13 year professional research, developing and production experience;
2. Experienced and professional R&D team to provide customization services;
3. Producing transmitter core elements- PCB, supplying PCB for transmitter producers;
4. Highest accuracy up to 0.05%FS;
5. Various outputs I2C, SPI, 4~20mA, Hart, Modbus, Profibus-Pa, 0.5-4.5V, 0.2-2.9V and other analog outputs;
6. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
